This docking station by Delock can be connected to a computer with a USB-C™ DP Alt Mode or Thunderbolt™ 3, Thunderbolt™ 4 or Thunderbolt™ 5 port and provides a variety of interfaces. A monitor can be operated at the HDMI output port by a maximum resolution up to 4K. Three built-in USB Type-A and one USB-C™ port allow the use of peripherals.
Integrated Card Reader
In addition, the docking station with integrated card reader expands a PC or laptop by an SD and a Micro SD slot via the USB Type-C™ connection.
USB Power Delivery (USB PD 3.0) support up to 85 watt
The docking station has a USB Type-C™ Power Delivery port. If this port is connected to the power supply of the laptop or tablet, the host device is charged with up to 85 watts during operation.
Modern Design
The sturdy metal frame and the surface made of tempered glass not only provide the USB-C™ dock with durability but also give it a sophisticated look – featuring a stylishly integrated, illuminated Delock logo.
• Connectors:
1 x USB Type-C™ male
1 x HDMI female
3 x USB 5 Gbps Type-A female
1 x USB 2.0 USB Type-C™ female
1 x SD slot
1 x Micro SD slot
1 x USB Type-C™ PD female (power supply)
• Resolution up to 3840 x 2160 @ 60 Hz (depending on the system and the connected hardware)
• Transmission of audio and video signals
• Supports HDCP 1.4 and 2.2
• Supports HDR
• Input power PD port: 100 W, 15 W are used for the docking station
• Output power for host: max. 85 W
• LED logo
• Metal frame
• Top side made of tempered glass
• Cable length without connectors: ca. 15 cm
• Colour: anthracite
• Dimensions (LxWxH): ca. 116 x 44 x 12 mm
• Android 14.0 or above
• Chrome OS
• Linux Kernel 6.11 or above
• Mac OS 15.3.2 or above
• Windows 10/10-64/11
• iPad Air (4th Generation) or above
• iPad Pro (3rd Generation) or above
• iPhone 15 Pro or above
• Surface Pro 9
• Device with a free USB Type-C™ port and DisplayPort alternate mode or with a free Thunderbolt™ 3, Thunderbolt™ 4 or Thunderbolt™ 5 port
Package content
• USB-C™ docking station
• User manual
