This forked light barrier by Delock enables precise and reliable detection of small objects and is ideally suited as an object detector for automation, control, and monitoring applications.
Precise detection and flexible integration
Thanks to its high repeat accuracy and compact design, even very small objects can be reliably detected. The open cable ends allow for simple and flexible integration into a wide range of systems and applications.
• Connectors:
4 x open wires
• Pin assignment:
Pin 1 - VCC
pin 2 - GND
Pin 3 - Output 1 (ON when light-darkening)
Pin 4 - Output 2 (ON when light-input)
• Design: Type K
• Switching mode: L/D switchable (light-on / dark-on)
• Slot width: 5 mm
• Standard detection object: detection of opaque objects from a size of 0.8 x 1.2 mm
• Switching principle: PNP
• Switching frequency: 3 kHz
• Ambient light: < 1000 lux
• Repeat accuracy: ≤ 0.03 mm
• Operating temperature: -25 °C ~ 55 °C
• Relative humidity: 5 - 85 % (non condensing)
• Mounting hole diameter: ca. 3.2 mm
• Pitch of screw hole: ca. 19 mm
• Housing material: PC + ABS
• Colour: black
• Protection rating: IP50
• Protection circuit: overvoltage protection, reverse polarity protection
• Operating voltage: 5 - 24 V
• Residual voltage: < 1 V
• Current consumption: < 8 mA
• Length incl. connectors: ca. 2 m
• 1 x forked light barrier
